The Goodman GLXS5 Air Conditioner uses the environmentally friendly refrigerant R-32 and features the unique Goodman sound control top design for quiet operation. In addition, the unit has an attractive louvered metal guard that protects the coil from damage plus a powder-paint finish that provides premium durability and improved UV protection.
Standard Features:
- High-Efficiency Scroll Compressor
- Copper tube/ enhanced aluminum fin coil-5mm diameter
- Factory-installed filter drier
- Fully charged for 15 feet of tubing length
- Service valves with sweat connections and easy-to-access gauge ports
- Enclosed contactor
- Ground lug connection
- High-pressure switch
- Capacitors with extended life
- ARI Certified; ETL Listed
Cabinet Features:
- Removable grille-style top design compliant with UL 60335-2-40
- Venturi for increased velocity of airflow
- Heavy-gauge galvanized-steel cabinet
- Attractive Architectural Gray powder-paint finish with 500-hour salt-spray approval
- Steel louver coil guard
- Wire fan discharge grille
- Top and side maintenance access
- Single-panel access to controls with space provided for field-installed accessories
Product Specification
| Model Number(s) | GLXS5BA2410 |
| Brand | Goodman |
| Type | Air Conditioning |
| Category | Condensers |
| Ton | 2.0 Ton |
| SEER | 15.2 |
| Cooling Btu | 24,000 |
| Cooling Stage(s) | 1 |
| Compressor Stage | Single |
| Electrical Phase(s) | 1-Phase |
| Decibel Level (dB) | 69 |
| Refrigerant Type | R-32 |
| Height (Inches) | 32 |
| Width (Inches) | 29 |
| Depth (Inches) | 29 |
| Total Shipping Weight (lbs.) | 167 |
| Parts Warranty (Years) | 10 |
| Compressor Warranty (Years) | 10 |
| UPC # | 663051735477 |
- GLXS5B Installation Manual
- GLXS5B Specifications Sheet
- GLXS5B Service Manual
- Goodman Condenser Warranty
